MOXA CSM-200-1218 slide-in Ethernet-to-Fiber Media Converters
- 1 x 10/100Mbps T(x) port and 1 x 100Mbps F(x) single-mode port with SC connector
- 12 VDC input power
- 0 to 55°C operating temperature
- LFP (Link Fault Pass-Through) and FEF (Far End Fault)
- Two different operation modes: store-and-forward and pass-through
- Auto-negotiation
- Plug and play
- Hot-swappable
Description
The CSM-200 slide-in Ethernet-to-fiber media converters are designed for the NRack System™. The modules provide media conversion from 10/ 100BaseT(X) to 100BaseFX (SC/ST connectors) and can be installed in any NRack System™ chassis.
You can also find the CSM-200-1213 and CSM-200-1214 models in the Industrial Media Converters.
You
can Buy the MOXA CSM-200-1218 slide-in Ethernet-to-Fiber Media Converters via inquiring online at competitive prices in the Middle
East (UAE (Dubai), KSA (Al Khobar, Riyadh), and
Oman). Enjoy the cost-effective shipping options
at a specific time in your location.
Specification
Interface | |
---|---|
10/100Mb RJ45 (Megabit) Ports | : 1 Port |
10/100/1000Mb RJ45 (Gigabit) Ports | |
100Mb Fiber optic multi mode (Megabit) Ports | |
100Mb Fiber optic single mode (Megabit) Ports | : 1 SC Port |
1000Mb SFP Fiber optic (Gigabit) Ports | |
M12 port | |
Alert Output | |
Standards and protocols | |
Protocols and work standards | IEEE 802.3u for 100BaseT(X) and 100BaseFX |
General | |
Maximum cable length for data transfer | 40Km with single mode fiber optic cable |
MTBF | 1,454,560 hrs |
Power Requirements | |
Power consumed | 180 mA @ 12 VDC |
Type of power input | - |
POE Support | |
Protection against overflow | |
LED Indicators | |
LNK/ACT | |
Buttons | |
DIP Switch | |
Physical Characteristics | |
Standards and Certifications | EMC, EMI, EMS, Safety, Vibration, Environmental Testing |
Housing | - |
Dimensions | 86.8 x 124.3 x 21 mm (3.42 x 4.89 x 0.83 in) |
Weight | 0.125Kg |
Operating Temperature | 0 to 55°C (32 to 131°F) |
Storage Temperature | -40 to 85°C (-40 to 185°F) |
Operation Humidity | 5 to 95% (non-condensing) |
Installation | can be installed in any NRack System™ chassis |
