Description
The DA-IRIGB-B-S module features 3 digital inputs and 4 digital outputs and provides precision timing information using IRIG-B input signals. The module is designed for embedded computers that support the PCI/104 interface.
You can also find the DE-LN04-RJ, DE-LN08-RJ, and DE-PRP-HSR-EF models in the Wide Temperature Computers.
You can Buy the MOXA DA-IRIG-B-S-02-T Expansion Module via inquiring online at a competitive price in the Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh) and Oman). Enjoy the cost-effective shipping options at a specific time in your location.
Specification
| INTERFACE | |
|---|---|
| Ports | 2 x DB9 male (1 x in, 1 x out) and 1 x ST Fiber port (in) |
| Connector | DB9 male, ST |
| Typical Distance | - |
| POWER REQUIREMENTS | |
| Power Information | - |
| PHYSICAL CHARACTERISTICS | |
| Dimensions | 167.64 x 106.68 mm (6.6 x 4.2 in) |
| Weight | 120 g (0.26 lb) |
| Operating Temperature | -40 to 75°C (-40 to 167°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Standards and Certifications | Green Product: RoHS, CRoHS, WEEE; Telcordia (Bellcore), GB |
| MTBF | 1,210,356 hrs |
