MOXA EXPC-F2120W-TL1-AC Panel Computer
- 12.1-inch Flat-Panel computer (1,200 nits)
- CPU: Intel® Celeron® 6305E
- 4 x 10/100/1000 Mbps ports (RJ45 connector)
- 3 x RS-232/422/485 ports (DB9 male connector)
- Aluminum body design (IP66 for front, IP42 for rear)
- 100 to 240 VAC input power range
- -40 to 70°C operating temperature
.png)
Description
The EXPC-F2120W Series consists of 12.1-inch panel computers
with an 11th Gen Intel Core™ i processor that delivers a reliable, durable, and
versatile platform for use in industrial, hazardous, and mission-critical
environments. The EXPC-F2120W panel computers come with a rich set of
communication interfaces to satisfy all your industrial application scenarios.
The panel computers are also provided with DisplayPort and VGA video outputs
for extending the display.
The EXPC-F2120W panel computers come in a fanless design
for operations in the -40 to 70°C temperature range and a streamlined enclosure
for efficient heat dissipation, making them the most reliable industrial
platforms available for harsh, hot, outdoor environments such as oil and gas
fields, drilling platforms, and power stations, as well as smart heater
solutions. The panel computers are also specifically designed with
sunlight-readable features such as a 1200-nit LCD panel, projected-capacitive,
glove-friendly, multi-touch screen, optical bonding, and anti-glare design, to
provide an excellent user experience for outdoor applications.
You can also find the EXPC-F2120W-TL1-DC and EXPC-F2120W-TL3-AC models in the Displays And Panel Computers.
Discover industrial automation solutions appropriate to your
needs, and easily inquire about the MOXA EXPC-F2120W-TL1-AC Panel Computer through our user-friendly website via
one of our Middle East branches (UAE (Dubai), KSA (Al Khobar, Riyadh), and
Oman).
Specification
| Computer | |
|---|---|
| CPU | Intel® Celeron® 6305E |
| Supported OS | Windows 10 Enterprise LTSC 21H2, Windows 11 Professional 23H2 64-bit, Debian 11 (driver) |
| OS (pre-installed) | OS is not pre-installed, OS installation via CTOS |
| System Memory | 16 GB (64 GB max) |
| Graphics Controller | Intel® UHD Graphics |
| Storage Slot | M.2 B key x 1 for SSD (internal, optional), CFexpress slots x 1 (external, default) |
| Interface | |
| LAN | 4 x Auto-sensing 10/100/1000 Mbps ports (RJ45 connector) |
| Digital Input/Output Channels | |
| Serial Ports | 3 x RS-232/422/485 ports, software selectable (DB9 male) |
| USB | 2 x USB 3.0 hosts, type-A connectors, 2 x USB 2.0 hosts, type-A connectors |
| Expansion Slot | M.2 B key slot x 1 for 5G module, M.2 E key slot x 1 for Wi-Fi module |
| Display | |
| Panel Size | 12.1 in |
| Aspect Ratio | 16:10 |
| Response Time | 18 ms (TR, gray to gray), 12 ms (TD, gray to gray) |
| Contrast Ratio | 750:1 |
| Viewing Angles | Horizontal: 85°/85°, Vertical: 85°/85° |
| Touch | Projective Capacitive touchscreen (PCAP), GGG sensor with optical bonding |
| Pixels | 1280 x 800 |
| Pixel Pitch (RGB) | 0.294 (H) x 0.294 (V) mm |
| Light Intensity | 1200 nits |
| Active Display Area | 304.128 (H) x 228.096 (V) mm |
| Max. No. of Colors | 16.7M (8-bit/color) |
| Serial Communication Parameters | |
| Baudrate | 50 bps to 115.2 kbps |
| Data Bits | 5, 6, 7, 8 |
| Stop Bits | 1, 1.5, 2 |
| Parity | None, Even, Odd, Space, Mark |
| Flow Control | RTS/CTS, XON/XOFF, ADDC (automatic data direction control) for RS-485, RTS Toggle (RS-232 only) |
| Serial Signals | |
| RS-232 | TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
| RS-422 | Tx+, Tx-, Rx+, Rx-, GND |
| RS-485-4w | Tx+, Tx-, Rx+, Rx-, GND |
| RS-485-2w | Data+, Data-, GND |
| LED Indicators | |
| System | Power x 1, Storage x 1, SSD |
| LAN | 2 per port, configurable by BIOS settings or via a Moxa software utility |
| Serial | 2 per port, configurable by BIOS settings or via a Moxa software utility |
| Power Requirements | |
| Input Voltage | 100 to 240 VAC |
| Power Consumption | 60 W (max), 100 W (with thermal heater) |
| Physical Characteristics | |
| Dimensions | 336.69 x 255.17 x 94.05 mm (13.25 x 10.05 x 3.70 in) |
| Housing | Aluminum |
| Operating temperature | -40 to 70°C (-40 to 158°F) |
| Storage Temperature | -45 to 75°C (-49 to 167°F) |
| Relative humidity | - |
| Standards and Certifications | EMC: EN 55032/35, EN 61000-6-2/-6-4; EMI: CISPR 32, FCC Part 15B Class A; EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m; 1.8, 2.6, 3.5, 5 GHz: 3 V/m, IEC 61000-4-4 EFT: Power: 2 kV(AC), 1 kV(DC); Signal: 0.5 kV, IEC 61000-4-5 Surge: Power: 2 kV (AC), 0.5 kV (DC L-L), 1 kV (DC L-G); Signal: 1 kV, IEC 61000-4-6 CS: 10 V, IEC 61000-4-8 PFMF; Hazardous Locations: EN / IEC 60079-0, EN / IEC 60079-7, EN / IEC 60079-15, Certification process underway; Mechanical Protection Rating: IEC 60529, IP code; Safety: UL 62368-1, EN 62368-1, IEC 62368-1; Shock: IEC 60068-2-27 compliant (with CFexpress card, 20G); Vibration: IEC 60068-2-27 compliant (with CFexpress card, 20G); UV Protection: IEC60068-2-5, CIE85: 300 to 3000 nm (included UV, visible, IR); 1000 hrs (procedure C; continuously for 24 hrs); IP66; IP42; Green Product: RoHS, CRoHS, WEEE |
| Weight | 6,200 g (13.67 lb) |
| Mounting | - |
