Name: MOXA PTC-101-S-SC-HV Ethernet To Fiber Converter
Brand: MOXA
Availability: InStock

MOXA PTC-101-S-SC-HV Ethernet To Fiber Converter

1 x 10/100BaseT(X) Ports (RJ45 connector)
1 x 100BaseFX Ports (single-mode SC connector)
40 KM Typical data transmission distance on fiber
100 to 240 VAC/VDC input power range
Metal body design
DIN-rail mounting
-40 to 85°C operating temperature

Brand: MOXA
Model: PTC-101-S-SC-HV

0 reviews • Write a review

Datasheet

Operating Temperature (-40 to 85°C)
Relative Humidity (5 to 95% non-condensing)
Vibration (IEC 60068-2-6)

Factory Automation
Power Utility

$0.00

Ex Tax: $0.00

Buy Now ENQUIRE NOW

Add to Wish List Compare this Product

From Same Category
Same Brand

Quickview

MOXA A52-DB25F w/ Adapter RS-232 to RS-422/485 Converter

$0.00

Ex Tax:$0.00

Add to Wish List Compare this Product

Quickview

MOXA A52-DB25F w/o Adapter RS-232 to RS-422/485 Converter

$0.00

Ex Tax:$0.00

Add to Wish List Compare this Product

Quickview

MOXA A52-DB9F w/ Adapter RS-232 to RS-422/485 Converter

$0.00

Ex Tax:$0.00

Add to Wish List Compare this Product

Quickview

MOXA A52-DB9F w/o Adapter RS-232 to RS-422/485 Converter

$0.00

Ex Tax:$0.00

Add to Wish List Compare this Product

Quickview

MOXA A53-DB25F w/ Adapter RS-232 to RS-422/485 Converter

$0.00

Ex Tax:$0.00

Add to Wish List Compare this Product

Quickview

MOXA A53-DB25F w/o Adapter RS-232 to RS-422/485 Converter

$0.00

Ex Tax:$0.00

Add to Wish List Compare this Product

Quickview

MOXA A53-DB9F w/ Adapter RS-232 to RS-422/485 Converter

$0.00

Ex Tax:$0.00

Add to Wish List Compare this Product

Quickview

MOXA A53-DB9F w/o Adapter RS-232 to RS-422/485 Converter

$0.00

Ex Tax:$0.00

Add to Wish List Compare this Product

Tags: Industrial Network Infrastructure , Ethernet Media Converters , Ethernet to Fiber Converters , Media Converters , Industrial Data Communications , Industrial Media Converters , Industrial Converters , Factory Automation Products , Power Utility Products , Converters , MOXA PTC-101 Series

The PTC-101 Ethernet-to-fiber media converters convert from 10/100BaseT(X) to 100BaseFX. Models are available with either SC, ST, or LC connectors. The PTC-101 converters eliminate the need for additional wiring, and support IEEE 802.3 and IEEE 802.3u/x protocols with 10/100M, full/half-duplex, and MDI/MDI-X auto-sensing to provide a total solution for your industrial Ethernet networks. The PTC-101 is compliant with mandatory sections of IEC 61850-3, covering operating temperature, power input voltage, surge, ESD, and vibration, as well as conformal coating and power insulation, making the media converters suitable for a variety of industrial applications.

You can also find the PTC-101-S-LC-HV, PTC-101-S-SC-LV, and PTC-101-S-ST-HV models in the Industrial Media Converters.

Inquire about the MOXA PTC-101-S-SC-HV Ethernet To Fiber Converter, designed for industrial automation solutions. Feel free to get in touch with our sales team to give you the best solutions at the best global price in the Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman).

eth to fiber : Interface
10/100Mb RJ45 (Megabit) Ports	Yes : 1 Port
10/100/1000Mb RJ45 (Gigabit) Ports	No
10/100Mb (Megabit) POE Ports	No
100Mb Fiber optic multi mode (Megabit) Ports	No
1000Mb Fiber optic multi mode (Gigabit) Ports	No
100Mb Fiber optic single mode (Megabit) Ports	Yes : 1 Port (SC connector)
1000Mb Fiber optic single mode (Gigabit) Ports	No
1000Mb SFP Fiber optic (Gigabit) Ports	No
M12 port	No
Alert Output	No
Magnetic Isolation Protection	1.5 kV (built-in)
eth to fiber : Standards and protocols
Protocols and work standards	IEEE 802.3, IEEE 802.3u/x
eth to fiber : General
Maximum cable length for data transfer	40 KM
MTBF	4,660,534 hrs
eth to fiber : Power Requirements
Input Voltage	100 to 240 VAC/VDC (85 to 264 VAC, 88 to 300 VDC)
Input Current	350 to 200 mA @ 100 to 240 VAC, 350 to 200 mA @ 100 to 240 VDC
Overload Current Protection	Supported
Type of power input	-
Power Consumption	350 to 200 mA @ 100 to 240 VAC, 350 to 200 mA @ 100 to 240 VDC
eth to fiber : Physical Characteristics
Standards and Certifications	EMC: EN 55032/35; EMI: CISPR 32, FCC Part 15B Class A; EMS: IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m, IEC 61000-4-4 EFT: Power: 4 kV; Signal: 4 kV, IEC 61000-4-5 Surge: Power: 4 kV; Signal: 4 kV, IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m; Signal: 10 V/m, IEC 61000-4-8 PFMF, IEC 61000-4-11; Environmental Testing: IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-3; Safety: EN 62368-1, UL 62368-1,, UL 60950-1; Vibration: IEC 60068-2-6; Power Substation: IEC 61850-3; Telcordia SR332
Housing	Metal
Dimensions	152.15 x 126.46 x 66.65 mm (5.99 x 4.86 x 2.62 in)
Weight	Packaged: 952 g (2.09 lb), Product only: 785 g (1.73 lb)
Operating Temperature	-40 to 85°C (-40 to 185°F)
Storage Temperature	-40 to 85°C (-40 to 185°F)
Operation Humidity	5 to 95% (non-condensing)
Installation	DIN-rail mounting
