Westermo MLC2-BiDi-B-DDM Fast Ethernet SFP Module
- 1 x 100 Mbit/s SFP port (Multimode, Simplex LC connector)
- 2 KM Typical data transmission distance on fiber
- Diagnostics: ±3°C Temperature at ± 0.1 VDC Voltage
- Maximum transmit wavelength: 1550 nm
- Wide operating temperature range, -40 to +85°C
- Brand: WESTERMO
- Product Code: 1100-0553
Description
The Westermo range of Fast Ethernet and Gbit/s multimode
SFPs offers cost-effective solutions for fiber installations in
mission-critical OT networks. These models can use fibers with a core of either
50 or 62.5 μm, depending on the required range and fiber availability. With
fully integrated DDM functionality in WeOS, it's possible to monitor parameters
such as temperature, TX/RX power, and voltage, ensuring optimal performance.
The range includes options for 100 Mbit/s and 1 Gbit/s,
ensuring compatibility with most Westermo switches, routers, and modems. The
Fast Ethernet and 1 Gbit/s transceivers are compatible with the Lynx, RedFox,
and ODW/MCW/SDW/LRW platforms with multiple options varying from 850 nm to 1550
nm.
All Westermo’s SFP transceivers are thoroughly tested in
accordance with high demands. Each model has gone through rigorous
environmental testing, to ensure that it can perform according to specification
even in the harshest environments. Furthermore, functionality is validated and
pushed to the limit, securing availability and reliability in mission-critical
applications.
WeOS, the Westermo operating system, is designed to meet the
toughest requirements, and full support for all offered transceivers is a
crucial aspect. All features of WeOS are extensively tested and verified to be
fully supported on any WeOS device with a Westermo transceiver installed.
You can also find the MLC2-DDM, MLC2-BiDi-A-DDM, GMLC550-DDM,
and GMLC2-DDM models in the SFP Transceivers.
Easy World Automation offers the easiest way to buy the Westermo MLC2-BiDi-B-DDM Fast Ethernet SFP Module in the Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman) at the lowest price through online inquiring. Our sales experts will contact you to fulfill all your industrial automation needs.
Specification
| INTERFACE | |
|---|---|
| Ports | 1 x 100 Mbit/s SFP port (Multimode) |
| Connector | Simplex LC connector |
| Typical Distance | 2 KM |
| POWER REQUIREMENTS | |
| Power Information | - |
| PHYSICAL CHARACTERISTICS | |
| Dimensions | Dimensions device: 14 x 13 x 57 mm (0.55 x 0.51 x 2.24 inches); Dimensions protrosion: 14 x 13 x 9 mm (0.55 x 0.51 x 0.35 inches) |
| Weight | - |
| Operating Temperature | -40 to +85°C (-40 to +185°F) |
| Storage Temperature | -40 to +85°C (-40 to +185°F) |
| Ambient Relative Humidity | 5-95% relative humidity |
| Standards and Certifications | EMC: EN 50121-4/IEC 62236-4, Railway signaling and telecommunications apparatus; Safety: EN/IEC 60825-1, Laser products - part 1: Equipment classification and requirement, EN/IEC 60825-2, Laser products - part 2: Safety of optical fiber communication systems, EN/IEC/UL 62368-1, Audio/video, information and communication technology equipment |
| MTBF | - |
