Description
With the switch in the 230V position the power-supply unit operates at low and moderate loads at any input voltage between 95 and 264 V AC (see ’Output’ at the right side).
You can place an order for the PULS SL2.100 DIN-rail Power supply online via one of our Middle East branches (Dubai/ Oman/Saudi Arabia) and get it delivered at a low cost at a specific time.
Specification
Input Data | |
---|---|
AC-Input Voltage | AC 100-120/200-240V |
DC-Input Voltage | DC 300V (-20%/+25%) |
EN61000-3-2(PFC-Norm) | fulfilled |
Output Data | |
nominal Voltage | 24Vdc |
Adjustment Range | 24-24V |
Output Current Range | 2.5A |
Output Current | 2.5A at 24V |
Output Power | 60W |
max. Ripple and Noise Voltage | 25mVpp |
Physical Characteristics | |
Mounting | DIN-Rail |
Dimension | 49mm x 124mm x 102mm |
Weight | 460g |
General | |
Connection method | Screw terminals |
E Classification | eClass 5.1 27049002, eClass 6.x 27049002, eClass 7.x 27049002, eClass 8.0 27049002, eClass 9.0 27040701, ETIM 4.0 EC000599, ETIM 5.0 EC002540, HS Code HS 85044082 |
Package Checklist | |
Packaging Unit | 1pc |
