Westermo 3623-0815 WLAN Antenna
- Frequency: 2.4 GHz / 5 GHz
- Antenna Type: Omni-directional
- Antenna gain: 2.4 GHz 1 dBi / 5.8 GHz 3.5 dBi
- Connector: 4 x QMA plug (m), Cable RADOX_RF_316, 1,5m
- IP68/IP69-rated Polycarbonate material design
- Cabinet/Ceiling mount installation
- -40 to 85°C operating temperature range
- Brand: WESTERMO
- Product Code: 3623-0815
.png)
.png)
Description
You can also find the 3623-0811, 3623-0812, 3623-0813, 3623-0814, 3623-0810, and 3623-0816 models in the Cables and Antennas.
Experience the convenient way to purchase the Westermo 3623-0815 WLAN Antenna in the
Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman). Our sales experts
will provide the most helpful information about the price and sale conditions
for a wonderful buying experience.
Specification
| Antenna Characteristics | |
|---|---|
| Frequency | 2.3 – 2.5 GHz, 4.-9 – 5.975 GHz |
| Antenna Type | Small Omni-directional 4x4 MIMO |
| Antenna Gain | 2.4 GHz 1 dBi / 5.8 GHz 3.5 dBi |
| Connector | 4x QMA plug (m), Cable RADOX_RF_316, 1,5m |
| Impedance | 50 Ω |
| HPBW/Horizontal | - |
| HPBW/Vertical | - |
| Polarization | Vertical |
| Power Handling | 10 W max. |
| V.S.W.R. | - |
| Physical Characteristics | |
| Dimensions | D, H: 145mm, 33.2mm |
| Operating Temperature | -45°C to +85°C |
| Storage Temperature | -45°C to +85°C |
| Length | - |
| Cable Length | 1,5m |
| Weight | 920 g |
| Ambient Relative Humidity | - |
| Housing | PC (Polycarbonate) |
| IP Rating | IP68, IP69 |
