Description
The IM Module Series has been designed for Moxa's EDS-728 Series and EDS-828 Series modular switches. The IM Module Series includes 6 Fast Ethernet modules, each with 4 ports supporting the TX, MSC, SSC, and MST media types. In addition, the IM Module Series includes 2 Gigabit Ethernet modules, one with 2 copper ports, and one with 2 fiber ports. Multiple modules can be used with the EDS-728 and EDS-828 switches, allowing each switch to support up to 24 Fast Ethernet ports and 4 Gigabit Ethernet ports.
End of Life Product - Replacement Available
Please note that the IM Module Series has been phased out and replaced by the LM-7000H Series.
You can Buy the MOXA IM-4MSC Fast Ethernet Module via inquiring online at a competitive price in the Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman). Enjoy the cost-effective shipping options at a specific time in your location.
Specification
| INTERFACE | |
|---|---|
| Ports | 4 x 100BaseFX Ports (multi-mode) |
| Connector | SC |
| Typical Distance | 5 KM on fiber |
| POWER REQUIREMENTS | |
| Power Information | Power Consumption: 6.6 W (max.) |
| PHYSICAL CHARACTERISTICS | |
| Dimensions | 40 x 127.8 x 100 mm (1.57 x 5.03 x 3.94 in) |
| Weight | 270 g (0.6 lb) |
| Operating Temperature | - |
| Storage Temperature | - |
| Ambient Relative Humidity | - |
| Standards and Certifications | Telcordia (Bellcore), GB |
| MTBF | - |
