The SFP-10G Series 1-port 10 Gigabit Ethernet SFP+ modules are available as optional accessories for a wide range of Moxa switches.
You can also find the SFP-10GERLC-T, SFP-10GLRLC-T, and SFP-10GZRLC-T models in the Ethernet SFP Modules.
Inquire about the MOXA SFP-10GSRLC-T 10 Gigabit Ethernet SFP+ Module, designed
for industrial automation solutions. Feel free to get in touch with our sales
team to give you the best solutions at the best global price in the Middle East
(UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman).
Specification
| INTERFACE | |
|---|---|
| Ports | 1 x 10GBase-SR (multi-mode) |
| Connector | Duplex LC |
| Typical Distance | 400 m |
| POWER REQUIREMENTS | |
| Power Information | - |
| PHYSICAL CHARACTERISTICS | |
| Dimensions | - |
| Weight | - |
| Operating Temperature | -40 to 85°C (-40 to 185°F), Note: When using the SFP-10GZRLC-T with the ICS-G7526A/G7528A/G7826A/G7828A and the MDS-G4000-4XGS/MDS-G4000-L3-4XGS Series, the maximum temperature is -10 to 60°C (14 to 140°F). |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Standards and Certifications | Safety: UL 62368-1, IEC 62368-1, IEC 60825-1; EMC: EN 55032/35; EMI: FCC 15B Test Report, ICES-003: 2020 Issue 7; EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m, IEC 61000-4-4 EFT: Power: 1 kV(AC), 0.5 kV(DC); Signal: 0.5 kV, IEC 61000-4-5 Surge: Power: 1 kV/2 kV(AC), 0.5 kV(DC); Signal: 1 kV, IEC 61000-4-6 CS: 0.15 MHz to 10 MHz: 3 V, 10 MHz to 30 MHz: 3 to 1 V, 30 MHz to 80 MHz: 1V., IEC 61000-4-8 PFMF: 1 A/m at 50 Hz, IEC 61000-4-11: Voltage Dips & Interruption |
| MTBF | - |
