MOXA ioLogik E2262 Smart Ethernet Remote I/O

MOXA ioLogik E2262 Smart Ethernet Remote I/O
MOXA ioLogik E2262 Smart Ethernet Remote I/O
MOXA ioLogik E2262 Smart Ethernet Remote I/O
MOXA ioLogik E2262 Smart Ethernet Remote I/O
MOXA ioLogik E2262 Smart Ethernet Remote I/O
MOXA ioLogik E2262 Smart Ethernet Remote I/O
MOXA ioLogik E2262 Smart Ethernet Remote I/O
  • 4 x Digital Output Channels
  • 8 x Thermocouple Channels
  • 1 x 10/100BaseT(X) Port (RJ45 connector)
  • 1 x RS-485 Serial port (Terminal block connector)
  • Plastic body design
  • Supports Modbus TCP, MX-AOPC, and SNMP v1/v2c
  • 12 to 36 VDC input power range
  • DIN-rail and Wall mounting
  • -10 to 60°C operating temperature


  • Brand: MOXA
  • Model: ioLogik E2262
0 reviews • Write a review
Datasheet User Manual
  • Operating Temperature (-10 to 60°C)
  • Relative Humidity (5 to 95% non-condensing)
  • Shock (IEC 60068-2-27)
  • Vibration (IEC 60068-2-6)
  • Freefall (IEC 60068-2-32)
  • Factory Automation
$0.00
Ex Tax: $0.00
Buy Now ENQUIRE NOW
Add to Wish List Compare this Product
MOXA 45ML-5401 Remote I/O Module
Quickview
MOXA 45ML-5401 Remote I/O Module
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
MOXA 45ML-5401-T Remote I/O Module
Quickview
MOXA 45ML-5401-T Remote I/O Module
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
MOXA 45MR-1600 Remote I/O Module
Quickview
MOXA 45MR-1600 Remote I/O Module
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
MOXA 45MR-1600-T Remote I/O Module
Quickview
MOXA 45MR-1600-T Remote I/O Module
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
MOXA 45MR-1601 Remote I/O Module
Quickview
MOXA 45MR-1601 Remote I/O Module
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
MOXA 45MR-1601-T Remote I/O Module
Quickview
MOXA 45MR-1601-T Remote I/O Module
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
MOXA 45MR-2404 Remote I/O Module
Quickview
MOXA 45MR-2404 Remote I/O Module
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
MOXA 45MR-2404-T Remote I/O Module
Quickview
MOXA 45MR-2404-T Remote I/O Module
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
Tags: Industrial Edge Connectivity , Controllers & I/Os , Universal Controllers & I/Os , Universal Controllers , Universal I/Os , Controllers , Smart Ethernet Remote I/O , Ethernet Remote I/O , Remote I/O Modules , Smart Remote I/O , Smart I/O , I/O Modules , I/Os , Modules , Industrial Automation Solutions , Remote Automation , Factory Automation Products. MOXA ioLogik E2200 Series

Moxa’s ioLogik E2200 Series Ethernet Remote I/O is a PC-based data acquisition and control device that uses proactive, event-based reporting to control I/O devices and features the Click&Go programming interface. Unlike traditional PLCs, which are passive and must poll for data, Moxa’s ioLogik E2200 Series will when paired with our MX-AOPC UA Server, communicate with SCADA systems using active messaging that is pushed to the server only when state changes or configured events occur. Additionally, the ioLogik E2200 features SNMP for communications and control using an NMS (Network Management System), allowing IT professionals to configure the device to push I/O status reports according to configured specifications. This report-by-exception approach, which is new to PC-based monitoring, requires far less bandwidth than traditional polling methods.


You can also find the ioLogik E2212-T, ioLogik E2210-T, ioLogik E2242, and ioLogik E2260 models in the Smart Remote I/O.


Experience the convenient way to purchase the MOXA ioLogik E2262 Smart Ethernet Remote I/O in the Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman). Our sales experts will provide the most helpful information about the price and sale conditions for a wonderful buying experience.

Remote I/O : Interface
Digital Input and Output Yes : 4 x Digital Output Channels
Adjustable digital input and output No
Analog Input and Output No
Relays No
Thermal sensor input (RTD) No
Thermocouple input Yes : 8 x Channels
LAN Yes : 1 x 10/100BaseT(X) Port (RJ45 connector)
Magnetic Isolation Protection 1.5 kV (built-in)
Serial port Yes: 1 Port
Isolation Yes : 3k VDC or 2k Vrms
Buttons Reset button
Remote I/O : Serial Interface
Connector Terminal block
Serial Standards RS-485
Serial Communication Parameters Baudrate: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps; Parity: None; Data Bits: 8; Stop Bits: 1; Flow Control: None
Serial Signals RS-485-2w: Data+, Data-, GND
Remote I/O : Security
Security Functions Authentication: Local database; Encryption: HMAC; Security Protocols: SNMPv3
Remote I/O : Standards and protocols
Protocols Ethernet: Modbus TCP Server (Slave), SNMPv1/v2c/v3, SNMPv1 Trap, Moxa AOPC (Active Tag), MXIO Library, CGI commands; Serial: Modbus RTU Master
Remote I/O : General
Compatible Softwares MX-AOPC UA Server, MXIO
Management BOOTP, IPv4, SMTP, DHCP Client, HTTP, TCP/IP
MTBF 341,063 hrs
Remote I/O : Power Requirements
Power Connector Screw-fastened Euroblock terminal
Input Voltage 12 to 36 VDC
Power Consumption 160 mA @ 24 VDC
Remote I/O : LED Indicators
LED Indicators PWR, RDY, Serial, I/O Status
Remote I/O : Physical Characteristics
Housing Plastic
Dimensions 115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)
Standards and Certifications Safety: UL 508; EMC: EN 61000-6-2/-6-4; EMI: CISPR 32, FCC Part 15B Class A; EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m, IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV, IEC 61000-4-5 Surge: Power: 1 kV, IEC 61000-4-6 CS: 10 V, IEC 61000-4-8 PFMF; Shock: IEC 60068-2-27; Vibration: IEC 60068-2-6; Freefall: IEC 60068-2-32; Green Product: RoHS, CRoHS, WEEE; Telcordia SR332
Installation DIN-rail mounting, Wall mounting
Operating Temperature -10 to 60°C (14 to 140°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Operation Humidity 5% to %95 Non-condensing
Weight 250 g (0.55 lb)
Altitude 2000 m
