Beijer NA-9289 Network Adapter Module

Beijer NA-9289 Network Adapter Module
Beijer NA-9289 Network Adapter Module

  • Modbus TCP server (slave)
  • 2 x Ethernet 10/100 MBPS
  • Up to 63 expansion modules
  • Built-in Ethernet switch
  • Web-server

  • Brand: BEIJER
  • Model: NA-9289
0 reviews • Write a review
  • Factory Automation
  • Power Utility
  • Marine
  • Railway Transportation
  • Road Transportation
  • Water & Wastewater
$0.00
Ex Tax: $0.00
Buy Now ENQUIRE NOW
Add to Wish List Compare this Product
Beijer BoX2 base protocol converter-IoT gateway-edge controller
Quickview
Beijer BoX2 base protocol converter-IoT gateway-edge controller
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
Beijer BoX2 extreme protocol converter-IoT gateway-edge controller
Quickview
Beijer BoX2 extreme protocol converter-IoT gateway-edge controller
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
Beijer BoX2 extreme SC protocol converter-IoT gateway-edge controller
Quickview
Beijer BoX2 extreme SC protocol converter-IoT gateway-edge controller
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
Beijer BoX2 pro SC protocol converter-IoT gateway-edge controller
Quickview
Beijer BoX2 pro SC protocol converter-IoT gateway-edge controller
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
Beijer iX T7B-SM graphic touch marine HMI
Quickview
Beijer iX T7B-SM graphic touch marine HMI
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
Beijer X2 extreme 12 HP SC Rugged HMI
Quickview
Beijer X2 extreme 12 HP SC Rugged HMI
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
Beijer X2 extreme 15 HP Rugged HMI
Quickview
Beijer X2 extreme 15 HP Rugged HMI
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product
Beijer X2 extreme 7 SL HP Rugged HMI
Quickview
Beijer X2 extreme 7 SL HP Rugged HMI
$0.00
Ex Tax:$0.00
Add to Wish List Compare this Product

Inquire about the Beijer NA-9289 Network Adapter Module, designed for industrial automation solutions. Feel free to get in touch with our sales team to give you the best solutions at the best global price in the Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman).

Beijer module : Communication serial
Serial interface No
Serial protocol No
Serial baud rate No
Beijer module : Communication ethernet
Ethernet baud rate 10/100 MBPS
Ethernet interface 2xRJ45
Ethernet protocol Modbus TCP
Beijer module : System
Program memory -
Non volatile memory -
Real-time clock -
Real-time clock accuracy -
Max expansion modules 63 slots
Maximum input size 126 words (252 bytes)
Maximum output size 126 words (252 bytes)
Web server Yes
Diagnostic -
Module error -
Beijer module : Power Requirements
Supply voltage 24 VDC (11 - 28.8 V)
Current consumption 10.0 A
Power connector Removable terminal block, cage clamp
Power supply protection Reverse polarity protection
Field power detection 11 VDC
Field power voltage 24 VDC (11 to 28.8V)
Beijer module : Physical Characteristics
Mechanical size -
Module weight -
Mounting 35mm DIN rail
System indicators Module Green/Red, Run Green, Error Green/Red, I/O Red, Field Power Green, Ethernet Link Yellow
Humidity 5-90% non-condensing
Operating temperature -20° to + 55°C
Storage temperature -40° to + 85°C
Marine No
