Westermo Lynx-RB-FT3G-MV Managed Ethernet Switch
- Layer 2/3 functionality switching and routing
- 3 x 1G combo SFP or copper ports for flexibility
- 1 x Console port (USB-C serial interface)
- IEEE 1588v2 Precision Time Protocol (PTP)
- DIN-rail mount installation design
- Redundant 24 -125 VDC power input
- IP40-rated metal body material
- -40 to +70°C operating temperature range
.png)
Description
The Lynx-RB-FT3G-MV is a compact redundancy box (RedBox)
supporting High Availability Seamless Redundancy (HSR) and Parallel Redundancy
Protocol (PRP). Its innovative features and robust construction make it the
ideal choice for mission-critical networks that demand uninterrupted data
communication. This device is designed for the highest possible system availability
and applications that require zero recovery time, such as electrical
substations. In addition, as cybersecurity threats become increasingly sophisticated, the Lynx-RB-FT3G-MV provides an extensive suite of tools to safeguard your network.
Designed to withstand the toughest environmental conditions,
the Lynx-RB-FT3G-MV is resilient against high EMI levels derived from load
switching and lightning strikes. It can also endure extreme ambient
temperatures, and with the use of exclusively industrial-grade components, it is
ideal for challenging industrial settings where reliability is paramount.
Compliance with industry standards is essential, and the Lynx-RB-FT3G-MV
fulfills the requirements of IEC 61850 and IEEE 1613, certified by KEMA.
With its compact and DIN-mounted design, the Lynx-RB-FT3G-MV
provides easy installation and saves valuable space in industrial environments.
It features three combo ports and a wide input redundant power supply,
maximizing flexibility and accommodating diverse network configurations.
The Lynx-RB-FT3G-MV industrial network device with RedBox
functionality delivers unparalleled performance, reliability, and security for
mission-critical industrial applications. Its advanced features, compliance
with industry standards, and robust construction make it the ideal choice for
ensuring uninterrupted and secure data communication in demanding industrial
environments.
You can also find the L106-S2, Lynx 3306-F2G-T4-LV, Lynx5512-F4G-T8G-LV, RedFox-5328-F4G-T24-HV, and Viper-112A-T3G models in the
Managed Ethernet Switches.
Enjoy the ease of online inquiries for the Westermo Lynx-RB-FT3G-MV Managed Ethernet Switch. You can
submit your inquiry on our website and get the friendliest communication with
our experts to choose high-quality industrial automation products at a
reasonable price from our Middle East branches (UAE (Dubai), KSA (Al Khobar,
Riyadh), and Oman).
Specification
| Interface | |
|---|---|
| Number of ports | 3 Ports |
| 10/100Mb RJ45 (Megabit) Ports | |
| 10/100/1000Mb RJ45 (Gigabit) Ports | |
| 100Mb Fiber optic multi mode (Megabit) Ports | |
| 100Mb Fiber optic single mode (Megabit) Ports | |
| 100Mb SFP Fiber optic (Megabit) Ports | |
| 1000Mb SFP Fiber optic (Gigabit) Ports | |
| 10/100Mb (Megabit) POE Ports | |
| 10/100/1000Mb (Gigabit) POE Ports | |
| Other ports | : 3 x 1G combo SFP or copper ports for flexibility, 1 x Console port (USB-C serial interface), 1 x digital output |
| Features and capabilities | |
| Backup | |
| LED Indicators | |
| LED Per Port | |
| Power Requirements | |
| Input Current | 0.3 A at 24 VDC, 0.075 A at 125 VDC |
| Power Input Plugin ( Redundant ) | |
| Input Voltage | 24 -125 VDC |
| Operating Voltage | 19.2 to 137.5 VDC |
| Power Consumption | - |
| General | |
| Fan / Fanless | Fanless |
| MTBF | Telcordia: 1,023,000 hours |
| Switch specifications | |
| Most forwarding speed | - |
| Network working layers | Layer 2/3 |
| Switch type | Managed |
| Port Aggregation | |
| Physical Characteristics | |
| Dimensions | 52 x 134 x 130 mm (2.05 x 5.28 x 5.19 inches) |
| Housing | Full metal |
| Installation | DIN-rail mounting |
| Operating Temperature | -40 to +70 °C (-40 to +158 °F) |
| Operation Humidity | 5-95 % relative humidity |
| Standards and Certifications | EMC: EN 50121-4/IEC 62236-4, Railway signalling and telecommunications apparatus, EN/IEC 61000-6-2, Immunity industrial environments, EN/IEC 61000-6-4, Emission industrial environments, EN/IEC 61000-6-5, Immunity power station and substation environment, EMI FCC Part 15, subpart B; Substation automation: IEEE 1613, Testing Requirements for Communications Networking Devices Installed in Electric Power Substations, IEC 61850-3, Communication networks and systems for power utility automation – Part 3: General requirements; Marine: DNV-CG-0339, Environmental test specification for electrical, electronic and programmable equipment and systems; Safety: EN/IEC/UL 61010-1, Safety requirements for electrical equipment for measurement, control, and laboratory use - Part 1: General requirements, EN/IEC/UL 61010-2-201, Safety requirements for electrical equipment for measurement, control, and laboratory use - Part 2-201: Particular requirements; Ingress protection: IP40; Telcordia; Shock: IEC 60255-21-2; Vibration: IEC 60255-21-1, IEC 60255-21-3, EN 60068-3-3, EN 60068-2-64, IEEE 1613 |
| Storage Temperature | -40 to +85 °C (-40 to +185 °F) |
| Weight | 960 g |
| Standards and protocols | |
| Protocols and work standards | IEEE 1588v2 Precision Time Protocol (PTP) |
| Protocols and management standards | Westermo configuration tool WeConfig, Web interface (HTTP and HTTPS), Command Line Interface (CLI) via console port, SSHv2 and Telnet, Local and Central Authentication (RADIUS/TACACS+), Role Based Access Control (RBAC), Password Compliance Policy, SNMPv1/v2c/v3, Secure Copy (SCP) for remote file upload and download, Local file management (via HTTP, FTP, TFTP and SCP), Load/save files from/to external memory, Configuration and Deployment using external memory, Tech support button, Flexible alarm and event handling system, RFC5424/RFC3164 Syslog (log files and remote syslog server) |
| Package Checklist | |
| Hardware installation guide | |
| Power adapter | |
| Power cable | |
