MOXA 85M-2600-T I/O Module

  • 16 x Digital Output Channels
  • Compatible with ioPAC 8600 or 8500 Series
  • Rugged and compact design for harsh environments
  • -40 to 75°C operating temperature

Description

Moxa’s ioPAC 8500 Series 85M Modules can be installed in both ioPAC 8500 and ioPAC 8600 Series devices. Modules are available with DI/Os, AIs, Fast AIs, and serial interfaces, giving users a wide variety of options to choose from and allowing them to select the I/O combination that best fits their target application. All 85M modules are designed for railway industry applications, and as such, are compliant with EN 50121-3-2, EN 50121-4, and a portion of the EN 50155 specifications. In addition, these modules all support a wide operating temperature range of -40 to 75°C for reliable operation even in harsh environments.


You can also find the 85M-3811-T and 85M-6600-T models in the Smart Remote I/O.


Experience the convenient way to purchase the MOXA 85M-2600-T I/O Module in the Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman). Our sales experts will provide you with the most helpful information about the price and sale conditions for a wonderful buying experience.

Specification

INPUT/OUTPUT INTERFACE
Digital Input and Output : 16 x Digital Output Channels
Analog Input and Output
System Power Input Channels
Thermocouple Channels
Field Power Input and Output
Relays
RTD Channels
Ethernet Ports
CAN Ports
Serial Ports
Isolation : 3k VDC or 2k Vrms
SERIAL INTERFACE
Connector -
Serial Communication Parameters -
Serial Signals -
GENERAL
MTBF 792,571 hrs
POWER REQUIREMENTS
Power Connector -
Input Voltage -
Power Consumption 35.4 mA @ 24 VDC
PHYSICAL CHARACTERISTICS
Housing -
Dimensions 25 x 128.2 x 85.5 mm (0.98 x 5.05 x 3.37 in)
Installation -
Storage Temperature -40 to 85°C (-40 to 185°F)
Weight Under 80 g
Ambient Relative Humidity 5 to 95% (non-condensing)
Operating Temperature -40 to 75°C (-40 to 167°F)
Standards and Certifications EMC: EN 55032/24, EN 61000-6-2/-6-4; EMI: CISPR 32, FCC Part 15B Class A; EMS: IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV, IEC 61000-4-3 RS: 5100 MHz to 6000 MHz: 3 V/m, IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV, IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV, IEC 61000-4-6 CS: 10 V, IEC 61000-4-8 PFMF; Railway: EN 50121-4, EN 50155; Safety: UL 508; Shock: IEC 60068-2-27; Vibration: IEC 60068-2-6; Telcordia SR332
Altitude 2000 m
