MOXA ioLogik R2110 Serial Remote I/O

  • 12 x Digital Input Channels, 8 x Digital Output Channels
  • 1 x RS-485 Serial port (Terminal block connector)
  • DIN-rail and Wall mounting
  • Supports Modbus/RTU protocol
  • 12 to 48 VDC input power range
  • -10 to 60°C  operating temperature

Description

The ioLogik R2100 Series was designed for system integrators to acquire and control remote analog devices over RS-485 connections. Different types of analog devices can be controlled, including sensors that read pH, conductivity, temperature, humidity, pressure, and flow, as well as actuators and valves. The ioLogik R2100 Series can be used with the standard Modbus protocol, and SCADA software or the MXIO DLL library can access the server.

Easy Remote Management

Traditionally, updating firmware over RS-485 was difficult for users. Moxa now provides an easy method for updating firmware over an RS-485 network, allowing users to perform remote firmware updates, reducing maintenance time and cost.



End of Life Product - Replacement Available

Please note that the ioLogik R2100 Series has been phased out and replaced by the ioLogik R1200 Series.



Experience the convenient way to purchase the MOXA ioLogik R2110 Serial Remote I/O in the Middle East (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman). Our sales experts will provide the most helpful information about the price and sale conditions for a wonderful buying experience.

Specification

Interface
Digital Input and Output : 12 x Digital Input Channels and 8 x Digital Output Channels
Adjustable digital input and output
Analog Input and Output
Relays
Thermal sensor input (RTD)
Thermocouple input
LAN
Magnetic Isolation Protection
Serial port : 1 RS-485 Port (Terminal connection)
Isolation : 3k VDC or 2k Vrms
Buttons
Serial Interface
Connector Terminal block
Serial Standards RS-485
Serial Communication Parameters Parity: None; Data Bits: 8; Stop Bits: 1; Flow Control: None; Baudrate: 1200 to 115200 bps
Serial Signals -
Security
Security Functions -
Standards and protocols
Protocols Modbus/RTU
General
Compatible Softwares -
Management -
MTBF -
Power Requirements
Power Connector -
Input Voltage 24 VDC nominal, 12 to 48 VDC
Power Consumption 282 mA typical @ 24 VDC
LED Indicators
LED Indicators I/O channels
Physical Characteristics
Housing Plastic top cover, metal bottom plate
Dimensions 115 x 79 x 45.63 mm (4.53 x 3.11 x 1.8 in)
Standards and Certifications Freefall: IEC 60068-2-32, EMI: FCC Part 15, CISPR (EN55022) class A, EMS: IEC 61000-4, IEC 61000-6, Shock: IEC 60068-2-27, Vibration: IEC 60068-2-6
Installation DIN-rail mounting, Wall mounting
Operating Temperature -10 to 60°C (14 to 140°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Operation Humidity 5% to %95 Non-condensing
Weight 200 g (0.44 lb)
Altitude -
