MOXA PTC-101-M-ST-HV Ethernet to Fiber Converter
- 1 x 10/100BaseT(X) Ports (RJ45 connector)
- 1 x 100BaseFX Ports (multi-mode ST connector)
- 5 KM Typical data transmission distance on fiber
- 100 to 240 VAC/VDC input power range
- Metal body design
- DIN-rail mounting
- -40 to 85°C operating temperature
Description
The PTC-101 Ethernet-to-fiber media converters convert from 10/100BaseT(X) to 100BaseFX. Models are available with either SC, ST, or LC connectors. The PTC-101 converters eliminate the need for additional wiring, and support IEEE 802.3 and IEEE 802.3u/x protocols with 10/100M, full/half-duplex, and MDI/MDI-X auto-sensing to provide a total solution for your industrial Ethernet networks. The PTC-101 is compliant with mandatory sections of EN 50155, covering operating temperature, power input voltage, surge, ESD, and vibration, as well as conformal coating and power insulation, making the switches suitable for a variety of industrial applications.
You can also find the PTC-101-M-ST-LV, PTC-101-M-SC-LV, PTC-101-M-SC-HV, and PTC-101-M-LC-LV models in the Industrial Media Converters.
You can explore our wide range of
products and enquire about the MOXA PTC-101-M-ST-HV Ethernet to Fiber Converter for your industrial automation needs. Our
sales experts will pave the way to buy at the lowest price in Dubai, UAE, Saudi
Arabia, Oman, and the Middle East.
Specification
| Interface | |
|---|---|
| 10/100Mb RJ45 (Megabit) Ports | : 1 Port |
| 10/100/1000Mb RJ45 (Gigabit) Ports | |
| 10/100Mb (Megabit) POE Ports | |
| 100Mb Fiber optic multi mode (Megabit) Ports | : 1 Port (ST connector) |
| 1000Mb Fiber optic multi mode (Gigabit) Ports | |
| 100Mb Fiber optic single mode (Megabit) Ports | |
| 1000Mb Fiber optic single mode (Gigabit) Ports | |
| 1000Mb SFP Fiber optic (Gigabit) Ports | |
| M12 port | |
| Alert Output | |
| Magnetic Isolation Protection | 1.5 kV (built-in) |
| Standards and protocols | |
| Protocols and work standards | IEEE 802.3, IEEE 802.3u/x |
| General | |
| Maximum cable length for data transfer | 5 KM |
| MTBF | 4,660,534 hrs |
| Power Requirements | |
| Input Voltage | 100 to 240 VAC/VDC (85 to 264 VAC, 88 to 300 VDC) |
| Input Current | 350 to 200 mA @ 100 to 240 VAC, 350 to 200 mA @ 100 to 240 VDC |
| Overload Current Protection | Supported |
| Type of power input | - |
| Power Consumption | 350 to 200 mA @ 100 to 240 VAC, 350 to 200 mA @ 100 to 240 VDC |
| Physical Characteristics | |
| Standards and Certifications | EMC: EN 55032/35; EMI: CISPR 32, FCC Part 15B Class A; EMS: IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m, IEC 61000-4-4 EFT: Power: 4 kV; Signal: 4 kV, IEC 61000-4-5 Surge: Power: 4 kV; Signal: 4 kV, IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m; Signal: 10 V/m, IEC 61000-4-8 PFMF, IEC 61000-4-11; Environmental Testing: IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-3; Safety: EN 62368-1, UL 62368-1,, UL 60950-1; Vibration: IEC 60068-2-6; Power Substation: IEC 61850-3; Telcordia SR332 |
| Housing | Metal |
| Dimensions | 152.15 x 126.46 x 66.65 mm (5.99 x 4.86 x 2.62 in) |
| Weight | Packaged: 952 g (2.09 lb), Product only: 785 g (1.73 lb) |
| Operating Temperature | -40 to 85°C (-40 to 185°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Operation Humidity | 5 to 95% (non-condensing) |
| Installation | DIN-rail mounting |
