MOXA NPort 5210-T Serial to Ethernet Device Server

  • 1 x 10/100BaseT(X) Port (RJ45 connector)
  • 2 x RS 232 Serial ports (8-pin RJ45 connector)
  • 12 to 48 VDC input power range
  • Desktop, DIN-rail, and Wall mounting
  • Metal body design
  • -40 to 75°C operating temperature

Description

The NPort 5200 serial device servers are designed to make your industrial serial devices Internet-ready in no time. The compact size of NPort 5200 serial device servers makes them the ideal choice for connecting your RS-232 (NPort 5210/5230/5210-T/5230-T) or RS-422/485 (NPort 5230/5232/ 5232I/5230-T/5232-T/5232I-T) serial devices—such as PLCs, meters, and sensors—to an IP-based Ethernet LAN, making it possible for your software to access serial devices from anywhere over a local LAN or the Internet. The NPort 5200 Series has a number of useful features, including standard TCP/IP protocols and choice of operation modes, Real COM/TTY drivers for existing software, and remote control of serial devices with TCP/IP or traditional COM/TTY Port.

Standard TCP/IP Interface and Broad Choice of Operation Modes

NPort 5200 device servers can operate in TCP Server, TCP Client, or UDP operation mode, ensuring compatibility with software based on a standard network API (Winsock, BSD Sockets).

Real COM/TTY Drivers for Existing Software

With the Real COM/TTY drivers that are provided with each NPort, software designed for communication with COM/TTY ports can be instantly and seamlessly integrated into a TCP/IP network. This is an excellent no-fuss way to preserve your software investment and enjoy the benefits of networking your serial devices.


You can also find the NPort 5232I w/ Adapter, NPort 5232 w/ Adapter, and NPort 5210 w/ Adapter models in the Serial-to-Ethernet Converters.


You can explore our wide range of products and enquire about the MOXA NPort 5210-T Serial to Ethernet Device Server for your industrial automation needs. Our sales experts will pave the way to buy at the lowest price in Dubai, UAE, Saudi Arabia, Oman, and the Middle East.

Specification

Interface
10/100Mb RJ45 (Megabit) Ports : 1 Port
100BaseFX Ports
Digital Input Channels
Digital Output Channels
Alarm Contact Channels
Magnetic Isolation Protection 1.5 kV (built-in)
Protocols -
Serial Interface
Number of Ports 2 Ports
Serial Standards RS-232
Connector 8-pin RJ45
Console Port
Serial Communication Parameters
Baudrate Supports standard baudrates (unit=bps): 110, 134, 150, 300, 600, 1200, 1800, 2400, 4800, 7200, 9600, 19200, 38400, 57600, 115200, 230400
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2
Parity None, Even, Odd, Space, Mark
Flow Control RTS/CTS (RS-232 only), DTR/DSR (RS-232 only), XON/XOFF
Isolation
Serial Signals
RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422 -
RS-485-4w -
RS-485-2w -
Communication details
Wireless Standards
Maximum data transfer speed
Maximum direct range
General
Management DHCP Client, IPv4, SNTP, SMTP, SNMPv1, DNS, HTTP, ARP, BOOTP, UDP, TCP/IP, Telnet, ICMP
Compatible operating systems Windows 11/10/8.1/8/7/Vista/XP/ME/98/95, Windows Server 2022/2019/2016/2012 R2/2012/2008 R2/2008/2003/2000/NT, Windows Embedded CE 5.0/6.0, Windows XP Embedded
Fixed TTY Drivers macOS versions: 10.12 to 10.15, 11.x, SCO UNIX, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X
Linux Real TTY Drivers Kernel versions: 6.x, 5.x, 4.x, 3.x, 2.6.x, and 2.4.x
MTBF 381,342 hrs
Automatic Reboot Trigger Built-in WDT
Power Requirements
Connection 1 removable 3-contact terminal block(s)
Input Voltage 12 to 48 VDC
Input Current 325 mA @ 12 VDC
Security
Security
Encryption
Authentication Local database (password only)
Features and capabilities
Display
Physical Characteristics
Dimensions with ears: 90 x 100.4 x 22 mm (3.54 x 3.95 x 0.87 in), without ears: 67 x 100.4 x 22 mm (2.64 x 3.95 x 0.87 in)
Installation Desktop, DIN-rail mounting (with optional kit), Wall mounting
Standards and Certifications EMC: EN 55032/35; EMI: CISPR 32, FCC Part 15B Class A; EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m, IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV, IEC 61000-4-5 Surge: Power: 1 kV, IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m, IEC 61000-4-8 PFMF, IEC 61000-4-11; Safety: UL 60950-1; Medical: EN 55011: 2007+A2: 2007 Class A (Group 1) compliant, EN 60601-1-2: 2007 compliant; Green Product: RoHS, CRoHS, WEEE; Telcordia (Bellcore) Standard TR/SR
Housing Metal
Operating Temperature -40 to 75°C (-40 to 167°F)
Storage Temperature -40 to 75°C (-40 to 167°F)
Operation Humidity 5 to 95% (non-condensing)
Weight 340 g (0.75 lb)
