MOXA CB-108 Serial Module Board
- 8 x RS-232 Serial ports
- 921.6 kbps maximum baudrate for fast data transmission
- On-chip hardware and software flow control
- Onboard Tx and Rx LED indicators for each port
- Supports Windows, Windows CE 5.0/6.0, and Windows XP Embedded operating systems
- Easy maintenance with built-in LEDs and management software
- With PC/104-Plus CPU boards that accept the PC/104-Plus expansion interface
- Brand: MOXA
- Product Code: CB-108
Description
The CB-108 PC/104-Plus modules come with 8 RS-232 ports and can be used with PC/104-Plus CPU boards that accept the PC/104-Plus expansion interface. Optional DB9 and DB25 connection cables are available for connecting to serial devices, and versatile driver support makes the modules suitable for a wide range of applications. The CB-108 modules can be used on the PC/104-Plus (PCI) bus, and provide a reliable, high-performance solution for multiport serial communication.
You can also find the CB-108-T model in the PCI Multiport Serial Cards.
You
can Buy the MOXA CB-108 Serial Module Board via inquiring online at a competitive price in the Middle
East (UAE (Dubai), KSA (Al Khobar, Riyadh), and
Oman). Enjoy the cost-effective shipping options
at a specific time in your location.
Specification
| SERIAL INTERFACE | |
|---|---|
| Comm. Controller | 16C550C or compatible x 4 |
| Number of Ports | 8 |
| Bus interface | PC/104 plus bus |
| Serial Standards | RS-232 |
| Connector | 40-pin box header |
| Baudrate | 50 bps to 921.6 kbps |
| Stop Bits | 1, 1.5, 2 |
| Parity | |
| Flow Control | |
| Data Bits | 5, 6, 7, 8 |
| FIFO | 128 bytes |
| POWER REQUIREMENTS | |
| Power requirement | 153 mA @ 5 VDC |
| SERIAL SOFTWARE FEATURES | |
| Windows Drivers | Windows CE 5.0/6.0, and Windows XP Embedded operating systems |
| Linux Drivers | - |
| UNIX Drivers | - |
| GENERAL | |
| MTBF | 403,631 hrs |
| PHYSICAL CHARACTERISTICS | |
| Dimensions | 90 x 96 mm (3.54 x 3.78 in) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Operation Humidity | 5 to 95% (non-condensing) |
| Standards and Certifications | EMC, EMI, EMS, Environmental Testing, Safety, Vibration |
