MOXA EDS-505A-SS-SC Managed Ethernet Switches

  • 3 100Mbps ports and 2 100Mb single-mode optical fiber optic ports
  • Din-rail
  • Metal body

Description

The EDS-505A standalone 5-port managed Ethernet switches, with their advanced Turbo Ring and Turbo Chain technologies (recovery time < 20 ms), RSTP/STP, and MSTP, increase the reliability and availability of your industrial Ethernet network. Models with a wide operating temperature range of -40 to 75°C are also available, and the switches support advanced management and security features, making the EDS-505A switches suitable for any harsh industrial environment.


You can also find the EDS-505A-MM-ST-T, EDS-505A-T, and EDS-505A-MM-SC models in the DIN-Rail Ethernet Switches.


Discover industrial automation solutions appropriate to your needs, and easily inquire about the MOXA EDS-505A-SS-SC Managed Ethernet Switches through our user-friendly website via one of our Middle East branches (UAE (Dubai), KSA (Al Khobar, Riyadh), and Oman).

Specification

Interface
Number of ports 5 Ports
10/100Mb RJ45 (Megabit) Ports : 3 Ports
10/100/1000Mb RJ45 (Gigabit) Ports
100Mb Fiber optic multi mode (Megabit) Ports
100Mb Fiber optic single mode (Megabit) Ports : 2 SC Ports
1000Mb SFP Fiber optic (Gigabit) Ports
10/100Mb (Megabit) POE Prots
100Mb SFP Fiber optic (Megabit) Ports
10/100/1000Mb (Gigabit) POE Ports
Features and capabilities
Backup Turbo Ring, Turbo Chain, Automatic Backup Configurator (ABC-01), STP/RSTP, MSTP
LED Indicators
LED Per Port
Power
Power Requirements
Maximum power consumption -
Power Consumption (Output Adapter) 24V DC, 0.35A
Power Input Plugin ( Redundant )
General
Fan / Fanless
MTBF 352000 hour
Switch specifications
Most forwarding speed -
Network working layers Layer 2
Switch type Managed
Port Aggregation -
Physical Characteristics
Dimensions 80.2x135x105mm
Housing Metal
Installation Din-rail
Operating Temperature 0 to 60 ° C
Operation Humidity 5% to %95 RH non-condensing
Standards and Certifications CE/FCC, UL 60950-1, UL 508, UL/cUL Class 1 Div. 2, ATEX Zone 2, DNV/GL, IP30
Storage Humidity -
Storage Temperature -40 to 85 ° C
Weight 1.04Kg
Standards and protocols
Protocols and work standards IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1w for Rapid STP, IEEE 802.1s for Multiple Spanning Tree Protocol, IEEE 802.1Q for VLAN Tagging, IEEE 802.1p for Class of Service, IEEE 802.1X for Authentication, IEEE 802.3ad for Port Trunk with LACP
Protocols and management standards IGMPv1/v2, GVRP, SNMPv1/v2c/v3, DHCP Server/Client, BootP, TFTP, SNTP, SMTP, RARP, GMRP, LACP, RMON, HTTP, HTTPS, Telnet, Syslog, DHCP Option 66/67/82, SSH, SNMP Inform, EtherNet/IP, Modbus/TCP, LLDP, IEEE 1588 PTPv2, IPv6, NTP Server/Client
Package Checklist
Hardware installation guide
Power adapter
Power cable
